PS4 3.11 Out of Bound Read (Freetype 64bit Exploit) via Dragood2

Despite Sony releasing PS4 Firmware 3.15 last night, dragood2 recently uncovered a PS4 3.11 Out of Bound Read (Freetype 64bit Exploit) that reportedly isn't patched in System Software Update 3.15.

Download: 38662.zip (Proof of Concept) / Source Code

Below are the details, although the usefulness of this has yet to be determined by PS4 developers, to quote:

The following heap-based out-of-bounds memory read has been encountered in FreeType. It has been reproduced with the current version of freetype2 from master git branch, with a 64-bit build of the ftbench utility compiled with AddressSanitizer:

$ ftbench <file>

Attached are three POC files which trigger the conditions.

---
$ freetype2-demos/bin/ftbench asan_heap-oob_783b6f_6837_eb01136f859a0091cb61f7beccd7059b

ftbench results for font `asan_heap-oob_783b6f_6837_eb01136f859a0091cb61f7beccd7059b'
-------------------------------------------------------------------------------------

family: (null)
style: (null)

number of seconds for each test: 2.000000

starting glyph index: 0
face size: 10ppem
font preloading into memory: no

load flags: 0x0
render mode: 0

CFF engine set to Adobe
TrueType engine set to version 35
maximum cache size: 1024KiByte

executing tests:
Load =================================================================
==22366==ERROR: AddressSanitizer: heap-buffer-overflow on address 0x60200000eb55 at pc 0x00000069e2fc bp 0x7fffc4670610 sp 0x7fffc4670608
READ of size 1 at 0x60200000eb55 thread T0
#0 0x69e2fb in tt_sbit_decoder_load_bit_aligned freetype2/src/sfnt/ttsbit.c:834:19
#1 0x69d214 in tt_sbit_decoder_load_bitmap freetype2/src/sfnt/ttsbit.c:1145:15
#2 0x69b1bf in tt_sbit_decoder_load_image freetype2/src/sfnt/ttsbit.c:1340:12
#3 0x69eee2 in tt_sbit_decoder_load_compound freetype2/src/sfnt/ttsbit.c:932:15
#4 0x69d214 in tt_sbit_decoder_load_bitmap freetype2/src/sfnt/ttsbit.c:1145:15
#5 0x69b1bf in tt_sbit_decoder_load_image freetype2/src/sfnt/ttsbit.c:1340:12
#6 0x6893d2 in tt_face_load_sbit_image freetype2/src/sfnt/ttsbit.c:1506:19
#7 0x55d265 in load_sbit_image freetype2/src/truetype/ttgload.c:2127:13
#8 0x55bedc in TT_Load_Glyph freetype2/src/truetype/ttgload.c:2487:15
#9 0x5301a2 in tt_glyph_load freetype2/src/truetype/ttdriver.c:396:13
#10 0x4f18ae in FT_Load_Glyph freetype2/src/base/ftobjs.c:742:15
#11 0x4e966e in test_load freetype2-demos/src/ftbench.c:250:13
#12 0x4e9c3f in benchmark freetype2-demos/src/ftbench.c:216:15
#13 0x4e80e9 in main freetype2-demos/src/ftbench.c:1058:9

0x60200000eb55 is located 0 bytes to the right of 5-byte region [0x60200000eb50,0x60200000eb55)
allocated by thread T0 here:
#0 0x4bc4a8 in malloc llvm/projects/compiler-rt/lib/asan/asan_malloc_linux.cc:40
#1 0x756740 in ft_alloc freetype2/src/base/ftsystem.c:74:12
#2 0x51b4e7 in ft_mem_qalloc freetype2/src/base/ftutil.c:76:15
#3 0x51abb1 in FT_Stream_EnterFrame freetype2/src/base/ftstream.c:269:12
#4 0x51a800 in FT_Stream_ExtractFrame freetype2/src/base/ftstream.c:200:13
#5 0x69ccab in tt_sbit_decoder_load_bitmap freetype2/src/sfnt/ttsbit.c:1036:10
#6 0x69b1bf in tt_sbit_decoder_load_image freetype2/src/sfnt/ttsbit.c:1340:12
#7 0x69eee2 in tt_sbit_decoder_load_compound freetype2/src/sfnt/ttsbit.c:932:15
#8 0x69d214 in tt_sbit_decoder_load_bitmap freetype2/src/sfnt/ttsbit.c:1145:15
#9 0x69b1bf in tt_sbit_decoder_load_image freetype2/src/sfnt/ttsbit.c:1340:12
#10 0x6893d2 in tt_face_load_sbit_image freetype2/src/sfnt/ttsbit.c:1506:19
#11 0x55d265 in load_sbit_image freetype2/src/truetype/ttgload.c:2127:13
#12 0x55bedc in TT_Load_Glyph freetype2/src/truetype/ttgload.c:2487:15
#13 0x5301a2 in tt_glyph_load freetype2/src/truetype/ttdriver.c:396:13
#14 0x4f18ae in FT_Load_Glyph freetype2/src/base/ftobjs.c:742:15
#15 0x4e966e in test_load freetype2-demos/src/ftbench.c:250:13
#16 0x4e9c3f in benchmark freetype2-demos/src/ftbench.c:216:15
#17 0x4e80e9 in main freetype2-demos/src/ftbench.c:1058:9

SUMMARY: AddressSanitizer: heap-buffer-overflow freetype2/src/sfnt/ttsbit.c:834:19 in tt_sbit_decoder_load_bit_aligned
Shadow bytes around the buggy address:
0x0c047fff9d10: fa fa fa fa fa fa fa fa fa fa fa fa fa fa fa fa
0x0c047fff9d20: fa fa fa fa fa fa fa fa fa fa fa fa fa fa fa fa
0x0c047fff9d30: fa fa fa fa fa fa fa fa fa fa fa fa fa fa fa fa
0x0c047fff9d40: fa fa fa fa fa fa fa fa fa fa fa fa fa fa fa fa
0x0c047fff9d50: fa fa fa fa fa fa fa fa fa fa fa fa fa fa fa fa
=>0x0c047fff9d60: fa fa fa fa fa fa fa fa fa fa[05]fa fa fa fd fa
0x0c047fff9d70: fa fa fd fa fa fa fd fa fa fa fd fa fa fa fd fa
0x0c047fff9d80: fa fa fd fa fa fa fd fa fa fa fd fa fa fa fd fa
0x0c047fff9d90: fa fa fd fa fa fa 04 fa fa fa 00 fa fa fa fd fa
0x0c047fff9da0: fa fa fd fa fa fa fd fd fa fa fd fd fa fa fd fd
0x0c047fff9db0: fa fa fd fd fa fa fd fd fa fa fd fd fa fa fd fd
Shadow byte legend (one shadow byte represents 8 application bytes):
Addressable: 00
Partially addressable: 01 02 03 04 05 06 07
Heap left redzone: fa
Heap right redzone: fb
Freed heap region: fd
Stack left redzone: f1
Stack mid redzone: f2
Stack right redzone: f3
Stack partial redzone: f4
Stack after return: f5
Stack use after scope: f8
Global redzone: f9
Global init order: f6
Poisoned by user: f7
Container overflow: fc
Array cookie: ac
Intra object redzone: bb
ASan internal: fe
Left alloca redzone: ca
Right alloca redzone: cb
==22366==ABORTING
---

The issue was reported in https://savannah.nongnu.org/bugs/?46379.



[B7U3 C50SS]

Will do @Chaos Kid !



[Jeff]

Try mounting a Linux disc and installing that? That's what I mean Linux won't do much on a game disc the way its encrypted in 3 different segments

How about sending tcp package is it possible on the ps4 it self?
With the linux js emulator?
I havent tried because i dont have time.

Then use

ps4-waker start [titleId] Start a specified title id

With https://www.npmjs.com/package/ps4-waker



[Chaos Kid]

How about sending tcp package is it possible on the ps4 it self?
With the linux js emulator?
I havent tried because i dont have time.

Then use

ps4-waker start [titleId] Start a specified title id

With https://www.npmjs.com/package/ps4-waker

Don't get me wrong but Hacks are not the first thing to any Dev it's abot the system and learning it. Anybody has a knowledge of how the ps3 HV works will understand this.
One I pointed out the fact about Linux disc instal due to things missing and 2 due to the fact the other software is floating on the web right infront of us n not just github but some1 who knows what the system software is has access to it



[BlueHex]

Has anyone else heard about that possibility of a DRM device for PS4?? like a dongle or an ODE? E4 flasher possibly?? Well maybe i wouldn't go as far as to say E4 flasher but.. you know. I've heard rumors that something like that is going to be taking off soon. maybe this has got to do with that in a big way? Yea? or. Nay?

any links to remors or where you heard them, i would like to investigate the matter



[B7U3 C50SS]

any links to remors or where you heard them, i would like to investigate the matter

Check out:
José Miguel (@zecoxao) | Twitter
https://twitter.com/zecoxao

and his posts.. you'll find a few things of interest.



[Chaos Kid]

Check out:
José Miguel (@zecoxao) | Twitter
https://twitter.com/zecoxao

and his posts.. you'll find a few things of interest.

There is quite alot in there actualy n sad thing is all the ode stuff incoming is some1 under all your noses. I have known for quite some time as I have trailed the work and development of it. There nothing special fpga and acts simillar to a protocol analyzer with triggering modules onboard.

Once you have managed to figure out how these systems work you can literally do anything to the system with many options available it can even make the system a complete open virtual system but takes a great knowledge and understanding on how to do it.
